Product Overview
New Vickers PVQ20-B2R-SE3S Hydraulic Pump 02-341558 *Genuine*
*
Series
PVQ
*
Displacement
21.1 cc/rev
*
Input Rotation
Right Hand Rotation
*
Input Shaft Type
Splined
*
Port Type
Standard
*
Inlet Port Size
1.6250 in SAE O-Ring
*
Port Location
Rear Ported
*
Outlet Port Size
1-5/8 in SAE O-Ring
*
Control Type
Pressure Compensator
*
Displacement Type
Open Circuit
*
Port Thread Size
1-5/8-12 SAE;1-1/16-12 SAE
*
Mounting Type
2-Bolt SAE B Flange
*
Peak Pressure
210 bar
*
Shaft Rotation
Right
*
Application
Mining Machinery, Injection Molding Machines, Metal Forming Machines, Oil and Gas Equipment, Conveyor Lines, Primary Metals, Metal Cutting Equipment
*
Bearing Life At Rated Pressure
8000 hours
*
Cold Start Temperature Limit
50 °C
*
Controller Type
Pressure Compensator
*
End Cover Material
Cast Iron
*
Fluid Cleanliness
ISO 18/13
*
Fluid Comp
SAE J183 FEB80
*
Housing Material
Cast Iron
*
Maximum Case Pressure
0.35 bar
*
Maximum Input Speed
1800 rpm
*
Noise Level
71 decibel
